Product Details:
Payment & Shipping Terms:
|
| Automatic Grade: | Automatic | Condition: | New |
|---|---|---|---|
| Warranty: | 2 Years | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Voltage: | Customer | Product Name: | Non-woven Fabric Production Line |
| Raw Material: | PP Chips | Application: | Disposable Nonwoven Fabric Product |
| Machine Type: | S/SS/SSS/SSSS/SMS/SMMS/SMSS/SSMMS | Color: | Requirements |
| Product Width: | 1600/2400/3200mm | Final Products: | Non Woven Fabric Roll |
| Name: | Nonwoven Machine | ||
| High Light: | non woven fabric machine,nonwoven fabric machine |
||
New condition pp spunbond nonwoven fabric machine with S/SS/SMS model
1. Technical Data&Application of PET SS Double Beam Spunbond Nonwoven Machine.
S Model ( Packagings, Agricultural Cover )
| Working Width | Fabric GSM | Consumption | Annual Output/Year |
| 1600mm | 9-250 | 130KW | 1500T |
| 2400mm | 9-250 | 180KW | 2400T |
| 3200mm | 9-250 | 200KW | 3000T |
| 4200mm | 9-250 | 300KW | 3800T |
SS Model ( Baby Diaper, Medical Products )
| Working Width | Fabric GSM | Consumption | Annual Output/Year |
| 1600mm | 10-250 | 200KW | 3000T |
| 2400mm | 10-250 | 250KW | 4800T |
| 3200mm | 10-250 | 300KW | 6000T |
| 4200mm | 10-250 | 450KW | 7500T |
SMS/SMMS/SSMS/SSMMS Model ( Filtration Material, Baby Diaper, Medical Products )
| Working Width | Fabric GSM | Consumption | Annual Output/Year |
| 1600mm | 15-250 | 400KW | 3500T |
| 2400mm | 15-250 | 600KW | 5000T |
| 3200mm | 15-250 | 800KW |
6500T |
2. Working process
Raw Material(Edge Material Recycling) - Extruder - Filter - Metering Pump - Spinning Box - Cooling Air Drawing( Up&Down Strenching Device ) - Web Forming Machine - Calender - Winding and Slitting Machine -Finished Products
