Product Details:
Payment & Shipping Terms:
|
Voltage: | 380V,Customer | Warranty: | 1 Year |
---|---|---|---|
Weight: | Customization | Automatic Grade: | Automatic,Semi-Automatic |
Dimension(l*w*h): | Customization | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Free Spare Parts,Online Support,Video Technical Support,Field Installation |
Power(w): | Customization | Condition: | New |
Certification: | CE/ISO9001 | Raw Material: | PP Chips,Polypropylene,100% POLYPROPYLENE GRANULE FIBER GRADE |
Product Name: | Non-woven Fabric Production Line,Non Woven Machine,PP Melt Blown Nonwoven Fabric Machine | Application: | Nonwoven Fabric Disposable Machine,manufacture |
Color: | Requirements,As Customer Require | Capacity: | 16-20 T/day |
Name: | Non Woven Fabric Face Mask Making Machine,non Woven Fabric | Product Width: | 1600 To 3200mm (final Nonwoven Product) |
Type: | Nonwoven Fabric Line,Automatic,Disposable Face Mask Making Machine,Production Line | Speed: | 200m/min |
High Light: | nonwoven fabric machine,nonwoven fabric making machine |
Technical Parameters ( Standard Specification) of Our Nonwoven Machine
|
|||||
|
Model No.
|
Gram Weight
|
MaxSpeed(m/min)
|
Capacity(T/Days)
|
Equipment Size
|
AL-S (single beam)
|
1.6m
|
10-180
|
200
|
4
|
15*10*13m
|
2.4m
|
7-8
|
15*10*13m
|
|||
3.2m
|
9-10
|
15*10*13m
|
|||
AL-SS (single beam)
|
1.6m
|
10-150
|
400
|
9-10
|
29*13*13m
|
2.4m
|
13-14
|
30*14*13m
|
|||
3.2m
|
18-19
|
32*15*13m
|
|||
AL-SSS (single beam)
|
1.6m
|
10-150
|
450
|
12-13
|
31*13*13m
|
2.4m
|
24-25
|
32*14*13m
|
|||
3.2m
|
28-30
|
34*15*13m
|
Technical Advantages
1) The whole line is well-structured and easy to operate.
Name: Filter
Brand: AL
Original: CHINA
Type: candle filter
Filter precision: 45um-60um
Filtration area: 2.5m² for 1.6m
3.5m² for 3.2m
Max pressure: 12mpa for 1.6m
16mpa for 3.2m
Heal source: heat- transfer oil
circular heating
Name: Spinning Box
Brand: AL
Original: CHINA
Orifice number: 11019 for 1.6m
17651 for 3.2m
Orifice diameter: ф 0,45mm
L/D= 4:1
Max temperature: 300℃
Name: Stretching Device
Brand: AL
Original: CHINA
Its function is drawing spinning spinning filaments into web forming machine by air.
Name: Calender
Brand: AL
Original: CHINA
Roller width: 2000mm for 1.6m
3600mm for 3.2m
Roller diameter: ф420mm-520mm
Roller pressure: ≤150kg/cm²
Speed: 10-150m/min for S type
10-300m/min for SS/SMS type
Motor: 30kw for 1.6m
45kw for 3.2m
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
