1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW

China 1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW supplier
1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW supplier 1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW supplier 1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW supplier 1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW supplier

Large Image :  1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW

Product Details:

Place of Origin: China
Brand Name: AL
Certification: CE,ISO9001
Model Number: AL-1600SMS,AL-2400SMS,AL-3200SMS

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: USD1080,000~4,000,000 FOBNINGBO
Packaging Details: Wooden case; carton
Delivery Time: 90~150 days
Payment Terms: T/T;L/C
Supply Ability: 20sets/year
Detailed Product Description
High Light:

PP Non Woven Fabric Making Machine

,

non woven fabric manufacturing machine



1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW





Quick Details :





1> Model : AL-1600SS , AL-2400SS , AL-3200S

2> Width : 1600 to 3200mm

3> Fabric :GSM :15~250 g

4> Speed : 0~350m/min

5> CE ; ISO9001







Parts Of PP Non Woven Fabric production Line:





Recycle extruder---->Main extruder---->Filter---->Metering pump---->Monomer suction device--->Spinning box---->Quenching air chamber---->Stretching device---->Web former---->Calender---->Winder---->Slitter

Spun-Laid Process And Technical Flow Chart:

Additive(Recycling offcut fabric)---->Raw material---->Melting---->Filtering---->Measuring ---->Spinning---->Cooling---->Stretching---->Web forming---->Calendering---->Winding----> Cutting---->Final product



1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW



General Information For Non Woven Fabric production Line





Model No. AL-1600SMS AL-2400SMS AL-3200SmS
Working Width 1600mm 2400mm 3200mm
Fabric GSM 15~250 15~250 10~250
Power Input 600KVA 800KVA 1000KVA
Consumption 400KW 600KW 800KW
Annual Output 3500T 5000T 6500T
Embossing Pattern Diamond, Oval
Fineness 1.5~2.5dtex







Final Non Woven Fabric

1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW

Fabric Usage



Medical and health : Operation suit, operation tablecloth, patient suit, exposure suit, respirator, packing bags etc.

Labor Safety Goods : Protect clothing, cover for car and motor, dust cover, raincoat, work clothes for spraying the paint etc.

Traveling Goods: Beach umbrella, beach suit , recovery bag etc.

Cleaning: Bay diaper, incontinent adult pad, sanitary napkin, filtering material etc.



1600mm 3500T SMS Non Woven Fabric Making Machine Low Consumption 400KW
