Product Details:
Payment & Shipping Terms:
|
Voltage: | 220V/380V,Customer | Warranty: | 1 Year |
---|---|---|---|
Weight: | Customization | Automatic Grade: | Automatic,Semi-Automatic |
Dimension(l*w*h): | Customization | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Free Spare Parts,Online Support,Video Technical Support,Field Installation |
Power(w): | Customization | Condition: | New |
Certification: | CE/ISO9001 | Raw Material: | PP Chips |
Product Name: | Non-woven Fabric Production Line,Non Woven Machine | Application: | Nonwoven Fabric Disposable Machine,manufacture |
Color: | As Customer Require | Capacity: | 3000 Tons/year |
Type: | Nonwoven Fabric Line |
Specification of Our Nonwoven Machine | |||||
AL-S (single beam) | Model No. | Gram Weight | MaxSpeed(m/min) | Capacity(T/Days) | Equipment Size |
1.6m | 10-180 | 200 | 4 | 15*10*13m | |
2.4m | 7-8 | ||||
3.2m | 9-10 |
Name: Filter
Brand: AL
Original: CHINA
Type: candle filter
Filter precision: 45um-60um
Filtration area: 2.5m² for 1.6m
3.5m² for 3.2m
Max pressure: 12mpa for 1.6m
16mpa for 3.2m
Heal source: heat- transfer oil
circular heating
Name: Spinning Box
Brand: AL
Original: CHINA
Orifice number: 11019 for 1.6m
17651 for 3.2m
Orifice diameter: ф 0,45mm
L/D= 4:1
Max temperature: 300℃
Name: Stretching Device
Brand: AL
Original: CHINA
Name: Calender
Brand: AL
Original: CHINA
Roller width: 2000mm for 1.6m
3600mm for 3.2m
Roller diameter: ф420mm-520mm
Roller pressure: ≤150kg/cm²
Speed: 10-150m/min for S type
10-300m/min for SS/SMS type
Motor: 30kw for 1.6m
45kw for 3.2m
After-sales service
Installation:
The seller will send 2 or 4 engineers to install, test the production line and train customers’ workers in buyers’ factory. It will take 1 month for whole installation and training.
Our location in YIwu,which is near Shanghai (around 300km) and Hangzhou( just 120km).
