Fabric GSM 15~250 SSS PP Non Woven Fabric Making Machine /Finess 1.5~2.5dtex
Quick details
1> Model : AL-1600SSS , AL-2400SSS , AL-3200SSS
2> Width : 1600 to 3200mm
3> Fabric :GSM :15~250 g
4> Speed : 0~300m/min
6> Fineness : 1.5~2.5dtex
5> CE ; ISO9001
Parts Of PP Non Woven Fabric Equipment :
Recycle extruder---->Main extruder---->Filter---->Metering pump---->Monomer suction device--->Spinning box---->Quenching air chamber---->Stretching device---->Web former---->Calender---->Winder---->Slitter
Spun-Laid Process And Technical Flow Chart:
Additive(Recycling offcut fabric)---->Raw material---->Melting---->Filtering---->Measuring ---->Spinning---->Cooling---->Stretching---->Web forming---->Calendering---->Winding----> Cutting---->Final product
General Information For PP Non Woven Fabric Equipment
| Model No. | AL-1600SSS | AL-2400SSS | AL-3200SSS |
| Working Width | 1600mm | 2400mm | 3200mm |
| Fabric GSM | 15~250 | 15~250 | 15~250 |
| Power Input | 800KVA | 950KVA | 1600KVA |
| Consumption | 600~800KW | 600~800KW | 600~800KW |
| Annual Output | 4700T | 6900T | 9200T |
| Embossing Pattern | Diamond, Oval | ||
| Speed | 10~300m/min | ||
| Fineness | 1.5~2.5dtex | ||
Final non woven fabric
Fabric Usage
SSS spun bonded non woven fabric is composed of continuous filament, have good tensile strength and elongation, mainly for health and medical non woven products.
