Multi function Diamond / Oval SSS Spunbond Machine 600KW-800KW

China Multi function Diamond / Oval SSS Spunbond Machine 600KW-800KW supplier

Large Image :  Multi function Diamond / Oval SSS Spunbond Machine 600KW-800KW

Product Details:

Place of Origin: China
Brand Name: AL
Certification: CE,ISO9001
Model Number: AL-1600SSS,AL-2400SSS,AL-3200SSS

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiations
Packaging Details: Wooden case; carton
Delivery Time: 150~180 days
Payment Terms: T/T;L/C
Supply Ability: 20sets/year
Contact Now
Detailed Product Description

High Speed 300m/min SSS Spunbond Machine Width 1600mm Fineness 1.5~2.5dtex





Quick details





1> Model : AL-1600SSS , AL-2400SSS , AL-3200SSS

2> Width : 1600 to 3200mm

3> Fabric :GSM :15~250 g

4> Speed : 0~300m/min

6> Fineness : 1.5~2.5dtex

5> CE ; ISO9001



Parts Of PP Spunbond Machine :





Recycle extruder---->Main extruder---->Filter---->Metering pump---->Monomer suction device--->Spinning box---->Quenching air chamber---->Stretching device---->Web former---->Calender---->Winder---->Slitter

Spun-Laid Process And Technical Flow Chart:

Additive(Recycling offcut fabric)---->Raw material---->Melting---->Filtering---->Measuring ---->Spinning---->Cooling---->Stretching---->Web forming---->Calendering---->Winding----> Cutting---->Final product







General Information For PP Spunbond Machine





Model No. AL-1600SSS AL-2400SSS AL-3200SSS
Working Width 1600mm 2400mm 3200mm
Fabric GSM 15~250 15~250 15~250
Power Input 800KVA 950KVA 1600KVA
Consumption 600~800KW 600~800KW 600~800KW
Annual Output 4700T 6900T 9200T
Embossing Pattern Diamond, Oval
Speed 10~300m/min
Fineness 1.5~2.5dtex







Final non woven fabric



Multi function Diamond / Oval SSS Spunbond Machine 600KW-800KW

Fabric Usage



SSS spun bonded non woven fabric is composed of continuous filament, have good tensile strength and elongation, mainly for health and medical non woven products.
